Overview

EREA 3 phase Autotransformer 0-230-400V 60kVA ATT 60000/IP65

Name: EREA 3 phase Autotransformer 0-230-400V 60kVA ATT 60000/IP65
Brand: EREA
SKU: ATT 60000/IP65
Price: 22168.12 EUR
Availability: InStock

Item No.: ATT 60000/IP65

Delivery time: Please contact us for current delivery times

(Price excluding VAT) €18.320,76

€22.168,12

Of betaal in termijnen vanaf €738,94 p/m. Meer info

Description

Technical specifications
Brand	EREA
Commercial Order Number	ATT 60000/IP65
EAN	5414503121288
Class	Three-phase autotransformer
Primary voltage	3x 0-230-400 Vac Y+N
Secondary voltage	3x 0-230-400 Vac Y+N
Rated power	60000VA (60KVA)
Degree of protection	IP65
Voltage drop (dU%)	1.15%
Efficiency (%)	99%
Pcu (W)	1125 W
Po (W)	295 W
Dielectric strength referred to frame (Vac)	2500 Vac
Standards	EN 60726 EN 60076
Application	For Industrial Applications
Protection class	Prepared for class I
Maximum ambient temperatur ta (°C)	40 °C
Temperature Class	F
Size A x B x C (mm)	669x469x518mm
Weight	276kg
Primary connection	Nut fastening M16
Secondary connection	Nut fastening M16
Finish	Vacuum and pressure varnish impregnated
