EREA 3 phase medical transformer 3x400V//230V 6,3kVA 230TMTHD6300

Item No.: 230TMTHD6300

Delivery time: Please contact us for current delivery times

(Price excluding VAT) 2.988,56


Of betaal in termijnen vanaf 120,54 p/m. Meer info

Technical specifications

Brand EREA
Commercial Order Number 230TMTHD6300
EAN 5414503119919
Class Energy Efficient Protection Transformer for Medical used Spaces
Primary voltage 3x 400 Vac Y+N
Secondary voltage 3x 230 Vac Y+N
Rated power 6300VA (6.3KVA)
Dielectric strength referred to frame (Vac) 2500 Vac
Dielectric strength to mass (Vac) 4500 Vac
Degree of protection IP00

EN 61558-2-15
EN 60752

Maximum ambient temperatur ta (°C) 50 °C
Application For medical used rooms
Protection class Prepared for class I
Temperature Class B
Voltage drop (dU%) 3%
Efficiency  96.9%
Pcu (W) 300 W
Po (W) 85 W
Size A x B x C (mm) 480x225x415mm
Size D (mm) 320mm
Size E (mm) 185mm
Weight 115kg
Primary connection Screw terminals
Secondary connection Screw terminals
Φ (mm) 11 mm
Finish Vacuum and pressure varnish impregnated


On request Special versions
Option Enclosure IP20 (accessory) -
Option Enclosure IP23 (accessory) -
Option Damper (accessory) SILENT BLOCK 50

Alternative Products For:

Amplimo ringkerntransformator?2x115V 2x45V 800VA V7025 Specificaties : Vermogen : 800VA Primaire wikkeling : 2x115V Secundaire...
Identification Brand Erea Articlenumber DR-SPS120W24V/BTE EAN 5414503118073 Electrical...
