Technical specifications |
| Brand | EREA |
| Commercial Order Number | STAB 500 |
| EAN | 5414503116253 |
| Class | AC Voltage Stabilizer |
| Primary voltage | 230V (195,5 - 264,5V)V AC |
| Secondary voltage | 230V AC (±1%) |
| Power | 500VA |
| Efficiency | > 98 % |
| Frequency | 50-60 Hz |
| Applications | For all applications requiring a "clean sweep" system (measurement instruments, automatic control circuits, computers) |
| Specific property | Correction time 20 V/sec Stability < 1% |
| Degree of protection | IP20 |
| Standards | EN-60950-1
EN-61000-6-3 |
| Max. ambient temperature Ta (°C) | 45 °C |
| Size A x B x C (mm) | 290x360x200mm |
| Weight | 10kg |
| Primary connection | Power cord |
| Secondary connection | Socket |
| |
Options |
| On request | Other voltage and power ratings
Connections with insulated wires and mains cables |
