EREA 1 phase isolating transformer for electronic applications 230V/Us Multi-voltage 63VA E 56TR63

Item No.: E 56TR63
73,88
(Price excluding VAT)
Description

Technical specifications

Brand EREA
Commercial Order Number E 56TR163
EAN 5414503003171
Class Single-phase isolating transformer for electronic applications - Upri 230V // Usec 0-16-18-20-24-26-28V 2x 0-16-18-20-24-26-28V - Power 63VA
Primary voltage 230 Vac
Secondary voltage 16-18-20-24-26-28-32-36-40-48-52-56 Vac
Power 63VA
Degree of protection IP00
Voltage drop (dU%) 16%
Dielectric strength to mass (Vac)) 4000Vac
Standards

EN 61558-2-4

EN 60742

Max. ambient temperature Ta (°C) 40 °C
Temperature class E
Application Control circuits, contactors and electronic applications
Prepared for class II
Efficiency 83%
Pcu (W) 10.09W
Po (W) 3.27W
Size A x B x C (mm) 83x70x82mm
Size D (mm) 62mm
Size E (mm) 50mm
Weight 1.36kg
Primary connection FAST-ON connectors 4,8 x 0,5 mm
Secondary connection FAST-ON connectors 4,8 x 0,5 mm
Finish Vacuum-encapsulated with synthetic resin
Φ (mm) 7mm

Options

On request Other voltage and power ratings
Connections with insulated wires and mains cables
