EREA 1 phase isolating transformer for electronic applications 230V/Us Multi-voltage 100VA E 62TR100

Item No.: E 62TR100
95,15
(Price excluding VAT)
Description

Technical specifications

Brand EREA
Commercial Order Number E 62TR100
EAN 5414503003188
Class Single-phase isolating transformer for electronic applications - Upri 230V // Usec 0-20-22-24-26-28,5-31V 2x 0-20-22-24-26-28,5-31V - Power 100VA
Primary voltage 230 Vac
Secondary voltage 20-22-24-26-28,5-31-40-44-48-52-57-62 Vac
Power 100VA
Degree of protection IP00
Voltage drop (dU%) 13%
Dielectric strength to mass (Vac)) 4000Vac
Standards

EN 61558-2-4

EN 60742

Max. ambient temperature Ta (°C) 40 °C
Temperature class E
Application Control circuits, contactors and electronic applications
Prepared for class II
Efficiency 86,3%
Pcu (W) 12.13W
Po (W) 3.25W
Size A x B x C (mm) 83x70x97mm
Size D (mm) 62mm
Size E (mm) 50mm
Weight 1.82kg
Primary connection FAST-ON connectors 4,8 x 0,5 mm
Secondary connection FAST-ON connectors 4,8 x 0,5 mm
Finish Vacuum-encapsulated with synthetic resin
Φ (mm) 7mm

Options

On request Other voltage and power ratings
Connections with insulated wires and mains cables
